Self Priming High Pressure Pump with Dual Closed Vane Impeller. 7.5 HP, 208-230/460 Volts, 50/60 Hz, 3 Ph (Three Phase) & Viton / Sil Carbide / Carbon Shaft Seal. 2 " FNPT Suction & Discharge, TEFC - Totally Enclosed Fan Cooled Motor Enclosure, 122 GPM Max Flow, Max Working Pressure. Image Shown with A200-90 Optional Base (Not Included).

Connections / Discharge (Inches)	2 " FNPT
Heads To (Feet)	270 Feet
HP	7.5
Hz	50/60
Impeller Material	Aluminum
Material	Cast Iron
Maximum Flow (GPM)	122 GPM
Maximum Operating Temperature	180°F (82°C)
Maximum Pressure (PSI)	150 psi (10.3 Bar)

Motor Enclosure Type	TEFC - Totally Enclosed Fan Cooled
Motor Frame Size	184JM
Phase	3 Ph (Three Phase)
Quick Specs	Model Shown with A200-90 Optional Base (Not Included)
Shaft Seal Material	Viton / Sil Carbide / Carbon
Valve / Seat / O-Ring	EPR / EPDM
Voltage	208/230/460
